Raytac announced both MDBT50Q-512K & MDBT50Q-P1M modules has extended the ambient temperature up to 105°C, following Nordic’s nRF52833’s specification.

nRF52833 Module MDBT50Q By Raytac Has Extended To 105°C Ambient Temperature
nRF52833 Module MDBT50Q By Raytac Has Extended To 105°C Ambient Temperature

Unlike a single component like SoC, modules acted as an integrated equipment which includes some other related components. To secure the module works under the latest environment request while Nordic nRF52833 released, Raytac ensured all related components meet the new temperature requirement with RF efficiency secured.

Today, we are pleased to announce nRF52833 modules:

MDBT50Q-512K: Chip Antenna

MDBT50Q-P512K: PCB Antenna

Both have successfully extended ambient temperature to 105°C which are the most ideal devices for a wide range of commercial and industrial applications.

Raytac Corporation 勁達國際電子有限公司

A BT5.2 & BT5.1 & BT5 & BT 4.2 module maker based on Nordic nRF52 & nRF51 solution

(nRF52840 & nRF52833 & nRF52832 & nRF52820 & nRF52810 & nRF52811 & nRF51822)

www.raytac.com          email: cs@raytac.com          Tel: +886.2.3234.0208

Nordic nRF52820 solution, MDBT50 series Module by Raytac

Nordic announced their 6th multi-protocol solution of nRF52 series with nRF52820, which supports Bluetooth Low Energy (BLE), Bluetooth mesh, Thread, Zigbee and 2.4GHz proprietary wireless connectivity.

Like other nRF52 siblings, nRF52820 highlights a powerful  64MHz 32bit Arm Cortex-M4 processor, includes 256Kb Flash Memory and 32Kb RAM, features of Bluetooth 5.2, 5.1 and 5 including long range and high-throughput of 2Mbits per second, as well as direction finding, low energy power control and low energy isochronous channels.

A full speed (12Mbits per second) USB 2.0 interface and 1.7~5.5V operation voltage bring a wide range of commercial and industrial wireless applications to nRF52820. To support nRF52820’s development, Nordic released SoftDevice S112, a new memory-optimized central stack. S112 now released as a alpha and will have full SDK (SDK V16.0.0) support coming in Q2 2020.

Raytac nRF52820 Module, MDBT50 Series
Nordic nRF52820 Modules by Raytac, MDBT50 Series

Come to visit Raytac at Embedded World 2020 #Hall 3 / 3-520

With over 1,000 exhibitors gathering in Nuremberg, Germany on 25 Feb.~27 Feb., 2020 , Embedded World already is one of  the biggest trade fair among the IoT Technologies.

Raytac is pleased to be in attendance and present our full range of module family based on Nordic nRF52840, nRF528333 and all others.

We welcome all developers come to meet us and look forward to seeing you there.

EW 2020-RaytacRaytac Join Embedded World 2020

Raytac Corporation 勁達國際電子有限公司

A BT5.1 & BT5 & BT 4.2 module maker based on Nordic nRF52 & nRF51 solution

(nRF52840 & nRF52833 & nRF52832 & nRF52810 & nRF52811 & nRF51822)

www.raytac.com          email: cs@raytac.com          Tel: +886.2.3234.0208



Raytac nRF52833 Series Module MDBT50Q & Demo Board Now Are Available

Just right at the start of 2020, we are happy to announce nRF52833 modules are now available!

Raytac’s nRF52833 series modules are introduced in 3 kinds of antenna options (Chip Ceramic / PCB / u.FL connector for external antenna) brings the best usability to meet different implements.

Chip Antenna Version: MDBT50Q-512K

PCB Antenna Version: MDBT50Q-P512K

u.FL Connector Version: MDBT50Q-U512K

Nordic nRF52833 Module Series.jpg

Change to nRF52833 module? Introduce What the Hardware & Firmware Perspective Need To Review!

Developer who currently are using nRF52840 based modules must be excited waiting for nRF52833’s distribution. Most developers are aware that nRF52833 supports long range, multi protocol and USB interface but has less RAM and Flash memory rather than nRF52840 and no doubt is the best alternative to have cost effective without extra efforts.

Raytac has released 3 models of nRF52833 based modules just at the same time when Nordic released, MDBT50Q-512K / MDBT50Q-P512K / MDBT50Q-U512K. Both nRF52840 and nRF52833 module are based on same form factor and pin out. To have quick visual identification finding the difference, Raytac’s nRF52833 modules are built by Green PCB but nRF52840 modules are Blue.

Raytac BLE Module-nRF52840 & nRF52833

Raytac Released nRF52833 Module / MDBT50Q Series

Nordic’s nRF52833 is an advanced mulitiprotocol SoC solution which supporting not only Bluetooth mesh, Thread, Zigbee but also latest BT5.1 direction finding capable radio. The solution is built around 64MHz Arm Cortex-M4 FPU, 512KB flash memory, and 128KB RAM memory with an extended industrial standard working temperature range of -40 °C to 105°C which is an ideal solution for commercial and industrial applications.

Raytac Corporation, a Taiwan based Bluetooth module maker, has selected Nordic nRF52833 solution building up MDBT50Q series modules. MDBT50Q series modules provide 3 kinds of antenna options (Chip Ceramic / PCB / u.FL connector for external antenna) brings the best usability to meet different implements. The modules have BT5.1 certification and FCC/IC/CE/RCM/Telec/KC/SRRC/NCC/WPC pre-certified, which are the optimized solution that makes it attractive in a very wide range of applications from a performance, time-to-market efficiency, and minimal Bill of Material (BOM) perspective.

MDBT50Q /nRF52833 modules is expected to have mass production by 2019/11, customer who are interested in nRF52833 series module may visit Raytac website for more information.

nRF52833 series module

Chip Antenna Version: MDBT50Q-512K

PCB Antenna Version: MDBT50Q-P512K

u.FL Connector Version: MDBT50Q-U512K

Raytac BLE Module-MDBT50Q-nRF52833

Raytac Corporation 勁達國際電子有限公司

A BT5.1 & BT5 & BT 4.2 module maker based on Nordic nRF52 & nRF51 solution

(nRF52840 & nRF52833 & nRF52832 & nRF52810 & nRF52811 & nRF51822)

www.raytac.com          email: cs@raytac.com          Tel: +886.2.3234.0208

New Distributor Announcement (Japan) – 丸紅情報システムズ株式会社

Raytac is glad to announce that we has expanded our distributor network to Japan with 丸紅情報システムズ株式会社 (Marubeni Information Systems Co. Ltd.).The distribution agreement covers sales, marketing, and support for Raytac Corporation’s full range of Modules lines, including Nordic’s proven nRF51 Series, nRF52 Series, and nRF52840 in the territory.

2019 Raytac Module Family

With recent solid demand and positive feedback receiving from market, we strongly believe that IoT is the future to enhance people’s life.

With Marubeni Information Systems Co. Ltd. join Raytac’s module distribution network, we truly expect he complementary of network portfolio can bring the opportunity and competitive advantage along with a speedy and convenient accessibility for developers.



丸紅情報システムズ株式会社

Marubeni Information Systems Co.,Ltd

Contact: Daisuke Yamashita

Sales Sec.1, Device Solutions Dept.

Manufacturing Solutions Div.

Address: Shinjuku Garden Tower, 3-8-2, Okubo,

Shinjuku-ku, Tokyo 169-0072 Japan

TEL:+81-3-4243-4160

FAX:+81-3-4243-4198

Emai: Yamashita-Daisuke@marubeni-sys.com

URL: http://www.marubeni-sys.com



Raytac Corporation 勁達國際電子有限公司

A BT5.1 & BT5 & BT 4.2 module maker based on Nordic nRF52 & nRF51 solution

(nRF52840 & nRF52832 & nRF52810 & nRF52811 & nRF51822)

www.raytac.com          email: cs@raytac.com          Tel: +886.2.3234.0208

Raytac nRF52 Modules Bluetooth Specification Updated to BT5.1

Raytac nRF52 series module now has been updated to BT5.1

QDID: 139361 / DID: D047708

Raytac Module BT5.1 Specification
Raytac Module BT5.1 Specification

Burn your firmware – onto MDBT50Q-RX that is

Hi there, folks!
So you have hopefully downloaded your IDE, you have written your code which you then plan to copy it over onto your MDBT50Q-RX and make it execute your master plan to take over the world!
Seriously, don’t underestimate the Nordic nRF52840 based MDBT50Q-RX. USB sticks with Bluetooth can do wonders 😉
So, first of all, in order to be able to burn your code onto the USB Dongle, you will have to know the nerdy parts which includes which pins you will have to connect to. In our very well documented specification sheet for MDBT50Q-RX on section 8 which is called “Reference Circuit”, you will find parts down to the left that has “3.3V/SWDIO/SWCLK/GND” marks on it:
MDBT50Q-RX Circuit
Further down in the specification sheet, in section 9, you will find pictures illustrating where exactly on the PCB you can find these pins:
Pin locationsNow we know what to look for and where they are, so now we have only got to tell you how to use them.

Some people might not know this, but for developing these things, you need to get something called J-Link to connect your MDBT50Q-RX to your desktop. However, since this J-Link, when buying the official one from SEGGER, is very expensive, we strongly recommend you to just buy the nRF52840-DK from Nordic Semiconductor as it can be used as a J-Link through their software development kit (SDK) called nRFgo Studio and is MUCH CHEAPER than the official J-Link from SEGGER is.
Sidenote: There are a couple of other reasons why you should just get your hands on a nRF52840-DK from Nordic Semiconductor instead of getting a SEGGER J-Link, but that’s not the topic of this post 😉

When this is done, this is finally how you connect your MDBT50Q-RX to your J-Link to make it all work:

MDBT50Q-RX and J-Link connection

Here you will have to pay attention to the fact that you have to connect J-Link pins 3, 5 & 9 to GND. Otherwise, you won’t be able to burn anything onto your dear MDBT50Q-RX.
The physical connection should look like this:

J-Link Cable Connection

Pay attention to the direction of the cable, because that will also matter. The direction we mean in this case is which way the slim strip of red is facing.

As we have just revised our MDBT50Q-RX, our customers who have been developing firmware for our USB dongle should take a look at our previous blog post in which we explain about the changes made or contact us directly at service@raytac.com

Have a good day and we at Raytac wish you smooth and happy tinkering 🙂
