Nordic nRF5340 Module MDBT53 and MDBT53V By Raytac Corporation

Nordic nF5340 is the first wireless SoC with dual core processors which aimed to optimized the performance of complex IoT applications and LE audios. The dual core contains a 1MB Flash / 512K RAM M4F MCU for application processor and another 256K Flash / 64K RAM for network. This structure remarkable optimized the performance also low power efficiency.

Raytac released 5 modules with 2 form factors, MDBT53 and MDBT53V,  with different antenna options for selection. The modules deployed nRF53 SoC supports high-speed SPI, QSPI, USB, I2C, I2S, and NFC interface and 105°C industrial temperature specification. BT5.3 pre-qualified, FCC/IC/CE/Telec (MIC)/KC/SRRC/NCC pre-certified is a MUST for all Raytac modules.

MDBT53 is a System-on-Module (aka SoM) with a good size of 9.3mm x 14.3mm and 48 GPIO which is an ideal dimension to fit in most applications. MDBT53 provides 3 antenna options, Chip antenna; PCB antenna; and u.FL connector for external antenna which deliver a maximum feasibility for most IoT projects. MDBT53-1M (Chip Antenna) MDBT53-P1M (PCB Antenna) MDBT53-U1M (u.FL Connector for External Antenna)

MDBT53V is designated for the application which has a space constraint design. A 7.8mm x 12.4mm with 25 GPIO is small enough to offer the opportunity of employing nRF5340 modules in the project. MDBT53V provides 2 options of antenna, Chip and PCB, for developers’ selection which is capable of optimizing the project plan in terms of performance and budgetary.  MDBT53V-1M (Chip Antenna) MDBT53V-P1M (PCB Antenna)
