Raytac Announces A nRF52 Solution Module, MDBT42Q-U (Deployed u.FL Connector for External Antenna)

Raytac today announces the u.FL connector version module, MDBT42Q-U series which selects Nordic nRF52832 and nRF52810 SoC to provide the Bluetooth Low Energy (Bluetooth LE, aka BLE) wireless connectivity for IoT applications.


LINE’s IoT platform “LINE Things”

LINE introduced an IoT platform “LINE Things” allows Bluetooth Low Energy  (BLE) devices integrated to LINE’s ecosystem through LINE Things and operate by LINE’s own developed LINE Front-end Framework (LIFF) application.

Line Things Framework

To introduce this edge cutting service network, LINE Things provides various development kits help developers easy reaching out the real scenario. The kit uses Raytac MDBT42Q-512KV2 module deployed Nordic nF52832 solution to built a completed LINE Things demo board, circuit diagram, hardware design reference, and even source code available published in GitHub.  At the mean time, LINE also proposed a LINE Things Developer Trial Program in progress.


LINE, as one of the most popular instance messaging service provider in the world, now has brought the connection evolution from individual communication to social community. Raytac encourages developers to explore the LINE Things by visiting the hyper link provide in the article or direct contact LINE to understand more about the benefit which may tremendous change crowd’s life in the near future.

Developers who are interested in Line Things may visit below link for registration
https://feedback.line.me/enquete/public/3545-3I7tVA5i

Message can use Chinese, English and Japanese, LINE Things staff in each country will respond.

Raytac Corporation 勁達國際電子有限公司
A BT5 & BT 4.2 & BTv4.1 module maker based on Nordic nRF51 & nRF52 solution
(nRF52840 & nRF52832 & nRF52810 & & nRF52811 &nRF51822)
www.raytac.com email: cs@raytac.com Tel: +886.2.3234.0208

New Distributor Announcement (Turkey & Egypt) – Özdisan Elektronik A.Ş.

Raytac is glad to announce that we has expanded our distributor network to Turkey and Egypt. The distribution agreement with Özdisan Elektronik A.Ş. covers FAE, Engineering, Sales, Marketing and support for Raytac Corporation’s full range of module lines, including nRF52840, nRF52811, nR52832 and nRF51 series in territory.

1640x856

Özdisan Elektronik A.Ş. was founded in 1980 and currently is the leading electronic components distributor in Turkey. The headquarter located in Istanbul and built up 4 sales offices and warehouse in major cities in Turkey cities(Istanbul, Ankara, Izmir, Bursa). Employed RD FAE capability to support the development and evaluation consultant and also Marketing & Sales service.

Not only distribution service, Özdisan Elektronik A.Ş. but also expanded business to PCB & PCB assembly, LED lighting solutions, aluminum coolers aimed to achieve the synergy collaboration all the way from product idea emerging, developing and mass production.

IoT now has become a part of people’s life experience and Bluetooth is the key protocol connecting between human and IoT appliance.

Raytac employees Nordic’s solution developed series of modules which is a recommended 3rd party module maker listed in Nordic website. All modules from Raytac comes with superior RF efficiency, reliable quality, Bluetooth certification granted, and FCC/IC/CE/Telec/KC/SRRC/NCC pre-certified. Developers who deployed Raytac’s module into products may save lots of efforts in RF design expertise and obtain the low cost and time-to-market efficiency.

With Raytac’ Bluetooth Low Energy module joined the line card, Özdisan Elektronik A.Ş.  expects to advance the service from the Bluetooth world connecting to an unlimited future.

logo

Contact Window

Okan Abdi
Genel Müdür Yardımcısı/Deputy General Manager
Özdisan Elektronik Paz. San. ve Tic. A.Ş.
email: oabdi@ozdisan.com Tel: +90 (61) 420 1882
website: www.ozdisan.com

İbrahim Ekmekçi
Saha Uygulama Mühendisi /Field Application Engineer
Özdisan Elektronik Paz. San. ve Tic. A.Ş.
email: iekmekci@ozdisan.com Tel: +90 (61) 420 1882 /Ext:230   Mobile: +90 (534) 014 78 76
website: www.ozdisan.com

CD卡-2

MDBT50Q-RX-ATM-1

Raytac Corporation 勁達國際電子有限公司
A BT5 & BT 4.2 & BTv4.1 module maker based on Nordic nRF51 & nRF52 solution
(nRF52840 & nRF52832 & nRF52810 & & nRF52811 &nRF51822)
www.raytac.com email: cs@raytac.com Tel: +886.2.3234.0208



Bluetooth – Current and soon-to-perish versions

Bluetooth has been around for quite some time, but that doesn’t mean that no one is a beginner when it comes to developing Bluetooth-based products. In fact, due to their recent updates, Bluetooth is becoming increasingly popular as demand for power efficient gadgets and wireless technology is increasing. Smart watches is just one of the many examples out there.

For each and every single one of these devices, you’ll first have to register your new product with Bluetooth-functions built in on Bluetooth SIG’s website. You will eventually register (and pay for) your product based on what version of the Bluetooth protocol that you’re using in the product and do so by purchasing a so called Declaration ID (DID).

Yes, a little exaggeration in the title, but that’s essentially what it comes down to. Bluetooth SIG is doing some major updates and changes to the Bluetooth protocol which includes getting rid of the more outdated versions.

There are quite a few versions of the Bluetooth protocol out there, but nowadays you will basically be advised to choose from 2 versions:
v.4.2 or v.5.0
These two versions would be, as I mentioned in the title, the two current versions of Bluetooth.

Although it might seem very simple at first, there are a few things that you need to understand the content of the announcements to fully grasp what these updates and changes mean. That, my friends, is today’s topic of this post.

Archived specifications

Deprecated and Withdrawn Specifications

When a specification reaches the end of its useful life, the Bluetooth® SIG may choose either to deprecate the specification, ending maintenance and restricting its use, or to withdraw the specification from use.

Bluetooth SIG – https://www.bluetooth.com/specifications/archived-specifications

What has changed recently is nothing new, but it’s big. What I mean is that similar changes have been done in the past, but since the market is more dependent on the technology now than before, it matters far more for people when the Bluetooth SIG do the same changes nowadays. Those changes are as follows:

On 01/28/2019, the following policy changes will be enacted:
– Creating new designs that implement deprecated or withdrawn specifications will not be permitted
– New products cannot be added to designs that implement withdrawn specifications
– You cannot pay a $25,000 fee to qualify a new design that implements a deprecated specification
– Purchased but unused $25,000 Declaration IDs will no longer be valid and the cost of any unused $25,000 Declaration IDs will be credited to your account



Bluetooth SIG – bluetooth.com

This piece of information tells us that the process of withdrawing specifications comes down to two different steps, namely deprecation and withdrawal.
While deprecation literally means “to stop use”, it is in this case the first step in the process of making a certain Bluetooth specification obsolete.
Then there’s a time gap between a certain specification gets deprecated until it’s withdrawn. During this gap, as mentioned above, no new designs can be paid for and/or registered and unused DID’s will be invalid. This is only to prevent new devices with deprecated Bluetooth specifications from being produced. To stop the “bloodline” of those specifications if you will. During this gap, however, you are still able to add new products that implement the same fundamental design (e.g. version updates) as you wish.

After this gap is over, when the specification in question is actually withdrawn, you will not be able to add any new products to any existing designs.

Got it? No? It’s alright. In fact, there’s a lot of information and it’s hard to put into context right away. Just to make things clear, let’s make an example:
Company R is currently developing a new device called RIC which implements Bluetooth 4.0 specifications. For now, everything’s alright and Company R can go right ahead with their developments.
When the Bluetooth core specification 4.0 becomes deprecated in Jan 28th, Company R can no longer come up with new product designs such as RIC-2 since that would count as a new design, but Company R can update their original device RIC as long as they don’t change the physical design.
Then, when the Bluetooth core specification 4.0 is finally withdrawn, Company R cannot update their product RIC anymore AND they cannot register new designs under Bluetooth core specification 4.0.

If you’re a developer who is very familiar with Bluetooth already, this information might already be, as certain people refer it as, “peanuts”. If you’re new to the Bluetooth world, however, this is a lot to take in and you might want to read up more about it. We hope this explanation made things clearer for you though 🙂

You can find more info at:
Bluetooth SIG – https://www.bluetooth.com/specifications/archived-specifications

Don’t forget that Raytac Corporation’s modules are all pre-certified with FCC, TELEC, IC, CE, RCM, KC and SRRC. The best part is that more is yet to come!
Take a look at our modules on our website: http://www.raytac.com



Come to visit Raytac at Embedded World #Hall 3 / 3-520

With over 1,000 exhibitors gathering in Nuremberg, Germany on 26 Feb.~29 Feb., 2019 , Embedded World has become one of  the biggest trade fair among the IoT Technologies.

RAYTAC27-20181220_lo

Raytac Released nRF52840 USB Dongle “MDBT50Q-RX”

Raytac released nRF52840 USB Dongle which deployed MDBT50Q-P1M module offers a Bluetooth 5 specification granted, FCC/IC/Telec(MIC)/KC/SRRC/NCC/WPC pre-certified, and CE/RCM compliant solution.

Raytac nRF52840 Dongle MDBT50Q-RX
Abstract molecule structure on dark blue color background. Vector illustration of Communication – network for futuristic technology concept

nRF52832 Module MDBT42Q Reel Package Now Is Available!

Raytac Corporation, a recommended 3rd-party module maker by Nordic Semiconductor, announced that MDBT42Q series module now provide a Reel Package option for customers’ selection.

nRF52832 module-Raytac MDBT42Q Package .JPG

New Distributor Announcement (Russia) – PR Electronics

Raytac is glad to announce that we has expanded our distributor network to CIS Countries (Russia), Ukraine, Latvia, Lithuania. The distribution agreement covers sales, marketing, and support for Raytac Corporation’s full range of Modules lines, including Nordic’s proven nRF51 Series, nRF52 Series, and nRF52840 in the territory.

Raytac Nordic Module Line

PR Electronics is a Distributor of Electronic components and Modules

with offices in Russia and Belarus. The company now has 51 employees and 4 sales offices.

Key market segments: Automation, POS terminals and vending systems, Telecommunications, Security systems, Medical, Navigation.

  • Management: ISO 9001:2015 qualified
  • Stock maintenance: Reliability and flexibility
  • Add-on financial logistics
  • Experienced sales team with technical background
  •  Quick technical support through trained FAEs

With recent solid demand and positive feedback receiving from market, we strongly believe that IoT is the future to enhance people’s life.

With PR Electronics’s join of Raytac’s module distribution network, we truly expect he complementary of network portfolio can bring the opportunity and competitive advantage along with a speedy and convenient accessibility for developers.



PR Electronics

Contact: Pavel Lyashenko

Tel: +7 (499) 500-56-40  / Телефон/Факс: +7 (499) 500-56-40

Fax: +7 (495) 937-13-27

Email: lyashenko@premier-electric.com

Website: www.prelectro.com

Address: Andronovskoe Roadway, 26, Moscow 111024 Russia

                  111024 г. Москва, Андроновское шоссе 26

спецификации Bluetooth Core  под версией 5

спецификации Bluetooth Core  под версией 4.2

спецификации Bluetooth Core  под версией 4.1

CD卡-2
Raytac Corporation
A BT4.1 & BT4.2 & BT5 module maker based on Nordic nRF51 & nRF52 solution
(nRF51822 & nRF51422 & nRF52832 & nR52810 & nRF52840)
www.raytac.com          email: cs@raytac.com          Tel: +886.2.3234.0208

Raytac MDBT40 Series Module (Nordic nRF51 Solution) BT4.2 Certification Granted

With coming depreciation and withdraw of Legacy Bluetooth Core Specification Version, BT4.1/BT4.0 has been defined to be withdraw in 1 July, 2020, which covered Nordic’s nRF51 series solution (Raytac MDBT40 series module).

Bluetooth SIG Announces Deprecation and Withdraw of Legacy Bluetooth Core Spec Version


To resolve this issue, Raytac has updated the MDBT40’s Bluetooth specification to BT4.2 with DID: D042310. Raytac MDBT40/MDBT40-P/MDBT40-n designed based on Nordic nRF51xxx SoC with integrated Bluetooth 4.2, Bluetooth 4.1, and Bluetooth 4.0 stack. MDBT40/MDBT40-P/MDBT40-n module incorporates: GPIO, UART, SPI, I2C, and ADC interfaces for connecting peripherals and sensors. The modules are all FCC/IC/Telec/CE/KC/SRRC/NCC/ANATEL/RCM pre-certified (MDBT40-P includes CNC/IFETEL), which can speed up customers’  easy hardware design, reduce BOM cost, and enhance Time-To-Market efficiency

The granted BT4.2 DID includes not only basic GATT, RF PHY and Link Layer, but also a completed coverage of BLE software stack: Proximity Profile; Heart Rate Profile; Health Thermometer Profile; Blood Pressure Profile; Running Speed & Cadence Profile; HID Over GATT Profile; Alert Notification Profile; Glucose Profile; Cycling Speed & Cadence Profile ; Mesh Profile which fully support customers to suit the needs of any application!     

D042310
Raytac nRF51822 BLE Module
Raytac Nordic Module Line
Raytac Corporation
A BT4.1 & BT4.2 & BT5 module maker based on Nordic nRF51 & nRF52 solution
(nRF51822 & nRF51422 & nRF52832 & nR52810 & nRF52840)
www.raytac.com          email: cs@raytac.com          Tel: +886.2.3234.0208

Raytac Central Role AT Command Module Released

Raytac AT Command Family

AT command module, an easy solution provides developers a quick breakthrough to Bluetooth connection. Without firmware effort needed, simply have commands setting on MCU and the start to enjoy the implement of bridging connectivity between devices through Bluetooth.

Raytac AT Command Family
Raytac AT Command Family

After Raytac’s Peripheral (Salve) role AT command module released, the demand of Central role has been highlighted by developers.

To have a completed solution, Raytac today announced Central role, as known as Master, AT command module released.

Part No.:

MDBT42Q-ATM (Chip Antenna Version)

MDBT42Q-PATM (PCB Antenna Version)

Specification Download (Please Click Me)

Differ from Peripheral role AT command module built by nRF52810 solution, Central role AT command module deployed Nordic nRF52832 which employees 64K RAM and 512K Flash Memory.

Central Role AT Command Module: MDBT42Q-ATM
Central Role AT Command Module: MDBT42Q-ATM

Central Role AT Command Module: MDBT42Q-PATM
Central Role AT Command Module: MDBT42Q-PATM

The AT command modules, same as Raytac’s all other lines,  are Bluetooth qualified (BT5/BT4.2) and FCC/IC/Telec/KC/SRRC/NCC pre-certified and CE compliant. A completed hardware and preloaded AT Command firmware solution not only simplify the designs and reduce BOM cost, but also waive the cost of regulatory burden and speed up time to market efficiency.
