Raytac Announces A nRF52 Solution Module, MDBT42Q-U (Deployed u.FL Connector for External Antenna)

Raytac today announces the u.FL connector version module, MDBT42Q-U series which selects Nordic nRF52832 and nRF52810 SoC to provide the Bluetooth Low Energy (Bluetooth LE, aka BLE) wireless connectivity for IoT applications.


Raytac MDBT42V, Small But Comprehensive

Raytac BT5 module MDBT42V series designed to provide developers of Internet of Things (IoT) and wearable connected products.
Nordic Module-nRF52832- MDBT42V.JPG

Raytac MDBT42Q Series Module built by Nordic nRF52810 Solution

 Raytac built up module based on nRF52810

Chip Antenna Version Part No. : MDBT42Q-192K
PCB Antenna Version Part No. : MDBT42Q-P192K
Dimension:  16 x 10 x 2.2 mm

Certification Granted: FCC / IC / CE / Telec / KC / SRRC / NCC

Module expected to start shipment by 2017/10

 FullSizeRender 7

Raytac Module Distributor List



To provide all customers and developers a quick and speedy service, Raytac has assigned several local distributor for quick action.

nRF52 Raytac Module Reflow Profile Reference

Raytac Corporation
A BT4.1 & BT4.2 module maker based on Nordic nRF51 & nRF52 solution
(nRF51822 & nRF51422 & nRF52832 & nRF51802)
Tel: +886.2.3234.0208
To help customers to proceed the SMT process, Raytac provides the Reflow Profile reference.
The Reflow Profile provided in below is considered as the reference only.
Due to SMT facility and solder paste may be different by each factory, Raytac is strongly suggesting all customers may proceed the trial run first to get the best and right reflow profile which works for their own facility.

Tutorial about Bluetooth low energy By Nordic

Raytac Corporation
A BT4.1 & BT4.2 & BT5 module maker based on Nordic nRF51 & nRF52 solution
(nRF51822 & nRF51422 & nRF52832 & nR52810 & nRF52840)
www.raytac.com          email: cs@raytac.com          Tel: +886.2.3234.0208
Check out our two-part video tutorial about #Bluetooth low energy. In this tutorial, Nordic gives a developer’s introduction to Bluetooth and the development tools offered.

Part 1/2: Introduction to Bluetooth low energy (BLE)

An application oriented introduction to Bluetooth low energy.

Part 2/2: Nordic Semiconductor’s development resources

An introduction to the development tools offered by Nordic:
  • Code walk-through of an SDK example
  • Tools: mobile apps, pc application (nRF Connect), sniffer
  • Information resources: devzone, infocenter

Steps to Qualify Your Bluetooth Products

Raytac Corporation
A BT4.1 & BT4.2 module maker based on Nordic nRF51 & nRF52 solution
(nRF51822 & nRF51422 & nRF52832 & nRF51802)
Tel: +886.2.3234.0208
To qualify a Bluetooth product always the issue make people headache.
Here, we summarized the procedure become simple steps to help readers to easy to follow
From Step 3~5, we are sincerely suggest readers to entrust BQB (Bluetooth Qualify Body) to provide the professional service to save time and energy according to our experience.

STEP 1 Become a membership

Adopter Membership: Free–> “Most customers pick”
Associated Membership: US$7,500 or US$35,000 (depends on company size)
For more detail of the benefit between different membership, please visit the link as below

STEP 2. Obtain Production Information from supplier or manufacturer

Make sure your chip supplier or module manufacturer has well certified or not.
All information can be refer to SIG’s QDID information in public.
Makes sure the supplier or manufacturers’ QDID has well certified including both Hardware and Profile QDID

STEP 2-1. Qualify Your Products

a. Customers can log in SIG’s website to create a project in Test Plan Generator.
b. Pick up the type of qualification, such as End Product/Subsystem/Component/Development tool/Test equipment…etc.)
c. Link Layer, Spec, Profile

STEP 3. Purchase the Declaration ID (DID)

Readers can buy the DID from SIG’s website directly.

STEP 4. Submit Qualification Document

The Qualification Documents must been signed by BQE (Bluetooth Qualify Engineer) by BQB

STEP 5. Create and Submit the qualification

STEP 6. Brand Your Bluetooth Product
