MDBT40 & MDBT42Q Specification Sheet Update

2017 年 05 月 26 日2017 年 07 月 17 日by Raytac CorporationLeave a comment

As Raytac’s module line now all complied with CE RED regulation, we have included some information in the updated specification sheet accordingly.

Customers who are interested may download the updated spec sheet in below link

MDBT40&MDBT40-P Spec Sheet (Nordic nRF51822 Solution).Pls click me to download!

MDBT42Q&MDBT42Q-P Spec Sheet (Nordic nRF52832 Solution).Pls click me to download!

Raytac Corporation

A BT4.1 & BT4.2 & BT5 module maker based on Nordic nRF51 & nRF52 solution

(nRF51822 & nRF51422 & nRF52832 & nRF51802 & nR52810 & nRF52840)

www.raytac.com Tel: +886.2.3234.0208

email: service@raytac.com

Raytac Blog

Nordic nRF52832 Module (Raytac MDBT42Q Series Module)

2017 年 01 月 20 日2017 年 01 月 20 日by Raytac CorporationLeave a comment

img_0720-%e6%8b%b7%e8%b2%9d img_0732-%e6%8b%b7%e8%b2%9d

Raytac Corporation has developed several module series based on Nordic nRF52832 solution, which is based on Bluetooth specification: BT4.2 and ready for BT5

MDBT42Q/MDBT42Q-P (called as MDBT42Q Series module in below) are the most friendly items that customers pay attention to.

MDBT42Q series module is a powerful, highly flexible ultra-low power multiprotocol module ideally suited for Bluetooth® low energy, ANT and 2.4GHz ultra low-power wireless applications. It is built based on Nordic nRF52832 SoC with 32-bit ARM® Cortex™-M4F CPU with 512kB + 64kB RAM with I2C, SPI, UART interface. With a widely certification granted, it can help all developers and customers have the benefit to speedy up the developing schedule and reliable quality.

Continue reading “Nordic nRF52832 Module (Raytac MDBT42Q Series Module)”

nRF52 Raytac Module Reflow Profile Reference

2016 年 10 月 13 日2016 年 10 月 13 日by Raytac CorporationLeave a comment

Raytac Corporation

A BT4.1 & BT4.2 module maker based on Nordic nRF51 & nRF52 solution

(nRF51822 & nRF51422 & nRF52832 & nRF51802)

www.raytac.com

Tel: +886.2.3234.0208

email: service@raytac.com
http://raytaccorp.blogspot.tw/2016/10/nrf52-raytac-module-reflow-profile.html

To help customers to proceed the SMT process, Raytac provides the Reflow Profile reference.

The Reflow Profile provided in below is considered as the reference only.

Due to SMT facility and solder paste may be different by each factory, Raytac is strongly suggesting all customers may proceed the trial run first to get the best and right reflow profile which works for their own facility.

MDBT42Q / MDBT42Q-P Safety Regulation Granted List

2016 年 10 月 11 日2016 年 10 月 11 日by Raytac CorporationLeave a comment

Raytac Corporation

A BT4.1 & BT4.2 module maker based on Nordic nRF51 & nRF52 solution

(nRF51822 & nRF51422 & nRF52832 & nRF51802)

www.raytac.com

Tel: +886.2.3234.0208

email: service@raytac.com
http://raytaccorp.blogspot.tw/2016/10/mdbt42q-safety-regulation-granted-list.html

Raytac MDBT42Q series module has following safety regulation granted.

Item: MDBT42Q / MDBT42Q-P

USA (FCC): SH6MDBT42Q

Canada (IC): 8017A-MDBT42Q

Japan( Telec): 201-260496

Korea (KCC): MSIP-CRM-ryt-MDBT42Q

China (SRRC): CMIIT ID: 2016DJ4571

Taiwan (NCC) : CCAM16LP1180T2 (MDBT42Q) / CCAM16LP1181T1 (MDBT42Q-P)

EU (CE): R&TTE V1.9.1 Report

nRF52832 ANT Protocol Stacks: S212 and S332 Available Now

2016 年 07 月 28 日2016 年 07 月 28 日by Raytac CorporationLeave a comment

Raytac Corporation

A BT4.1 & BT4.2 module maker based on Nordic nRF51 & nRF52 solution

(nRF51822 & nRF51422 & nRF52832 & nRF51802)

www.raytac.com

Tel: +886.2.3234.0208

email: service@raytac.com

http://raytaccorp.blogspot.tw/2016/07/nrf52832-ant-protocol-stacks-s212-and.html

http://bluetooth.tokyo

Quoted from “ANT Wireless Tech Update 22 July, 2016”

ANT Wireless announced the formal production release of the ANT and concurrent ANT/BLE protocol stacks designed for Nordic Semiconductor’s nRF52832 SoC. The S212 (ANT only) and the S332 (concurrent ANT/BLE) are now available for licensing and download at thisisant.com on the nRF52832’s SoftDevices tab.

https://www.thisisant.com/developer/components/nrf52832/#tab_protocol_stacks_tab%20%20or%20contact%20us

Developers currently using alpha versions of the S212 or S332 SoftDevices are encouraged to upgrade to the new production ready versions by agreeing to the updated license agreement and incorporating the production ready SoftDevices into their designs.

Note: In a move to simplify the licensing process, ANT Wireless has combined the evaluation terms of use and the commercial terms of use into a single license agreement.
