Raytac Product Change Notice (PCN) Announcement for Nordic nRF52832 Solution Module

Raytac would like to announce Product Change Notice (PCN-19121601) for all nRF52832 module lines include MDBT42Q / MDBT42 / MDBT42V series.


There is no panic for this PCN,  it is refer to module’s appearance changes only but no others. Raytac will remove YELLOW DOT marking on shielding for all modules produced based on Nordic nRF52832 (Build Code: EXX) V.2 SoC since 2020 (Date Code from 001).

In case there is anything unclear for this PCN , please do not be hesitated to contact Account Manger for further assistance.

Raytac Corporation 勁達國際電子有限公司

A BT5.1 & BT5 & BT 4.2 module maker based on Nordic nRF52 & nRF51 solution

(nRF52840 & nRF52833 & nRF52832 & nRF52810 & nRF52811 & nRF51822)

www.raytac.com          email: cs@raytac.com          Tel: +886.2.3234.0208

Raytac Product Change Notice (PCN) Announcement for Nordic nRF52810 Solution

Correspond to Nordic new revision of the IC with key changes (Nordic PCN No.: PCN-113 rev. 1.2)

Raytac would like to announce Product Change Notice (PCN-19082201) for below Module lines which are built based on Nordic nRF52810 Solution

nRF52810 IC Revisions & Variants.png

MDBT50Q Series Module Built By nRF52840 Rev. 2 (Build Code:DXX) Started Shipment

Nordic Semiconductor has updated nRF52840 SoC version from Rev.1 to Rev.2. Raytac announced that the module built by nRF52840 with Rev.2 SoC now has started the mass production shipment.

nRF52840 IC Version

Raytac Product Change Notice (PCN) Announcement for Nordic nRF52840 Solution

Raytac would like to announce Product Change Notice (PCN-19051001) for below Module lines which are built based on Nordic nRF52840 Solution


Correspond to Nordic new revision of the IC with key changes

(According to Nordic PCN No.: PCN-111 rev. 1.0)


nRF52840 SoC Revision changed from Rev.1 to Rev.2 (Build Code Changed
from CXX to DXX)

nRF52840 IC Version.png

Raytac Product Change Notice (PCN) Announcement for Nordic nRF52832 Solution

Dear Customers,

Correspond to Nordic new revision of the IC with key changes

(According to Nordic Information Notice No.: IN-105, rev.1.0)
nRF52832 SoC Build Code changed:

  1. nRF52832-QFAA from B00 to E00
  2. nRF52832-CIAA from B00/B10 to E00/E10

Raytac would like to announce Product Change Notice (PCN18033101) for below Module lines which are built based on Nordic nRF52832 Solution

Modules built by nRF52832 SoC Part no. Changed from

  1. From MDBT42Q-512K to MDBT42Q-512KV2
  2. From MDBT42Q-P512K to MDBT42Q-P512KV2
  3. From MDBT42-512K to MDBT42-512KV2
  4. From MDBT42-P512K to MDBT42-P512KV2
  5. From MDBT42V-512K to MDBT42V-512KV2
  6. From MDBT42V-P512K to MDBT42V-P512KV2

Customers those who have been developing products based on above modules please contact with service@raytac.com to request V2 samples for evaluation.

Reference Download Site

Nordic PCN and IN-105, rev.1.0

http://infocenter.nordicsemi.com/pdf/in_105_v1.0.pdf

Nordic Errata (nRF52832 Rev 2 Errata v1.1)

http://infocenter.nordicsemi.com/pdf/nRF52832_Rev_2_Errata_v1.1.pdf

PCN-18033101-1PCN-18033101-2
PCN-18033101-3
Raytac Corporation
A BT4.1 & BT4.2 & BT5 module maker based on Nordic nRF51 & nRF52 solution
(nRF51822 & nRF51422 & nRF52832 & nR52810 & nRF52840)
www.raytac.com            Tel: +886.2.3234.0208
email: service@raytac.com

Raytac Product Change Notice (PCN) Announcement for Nordic nRF52810 Solution

Dear Customers,
Raytac would like to announce Product Change Notice (PCN) for Module line: MDBT42Q-192K & MDBT42Q-P192K, which are built based on Nordic nRF52810 Solution.

PCN No.: PCN-17112201

Description of Change:

MDBT42Q-192K and MDBT42Q-P192K Modules of Nordic nRF52810 solution change PCB color from Blue to Green and remove the black dotting on metal shielding case.

Raytac MDBT40 / MDBT40-P 仕様変更の通知

Raytac Corporation

Bluetooth Module Maker based on Nordic nRF51 & nRF52 Solution

((Nordic nRF51822 & nRF51422 & nRF52832)
Bluetooth Specification Version: BT4.0 & BT4.1 & BT4.2
Tel: +886.2.3234.0208
email: service@raytac.com
日本での代理店への連絡は下記の通り。
株式会社フクミ (Fukumi corporation)
消費材企画開発Gr. LBTチーム (Consumer Products R&D Group, LBT team)
榊 和優 (Kazumasa Sakaki)
Tel : 03-5687-2890 (+81-3-5687-2890)
Mail : lbt_bt@fukumi.co.jp

ブログから引用。詳細は下記Link先へ。
BLEモジュールのRaytacよりMDBT40 / MDBT40-P (Nordic nRF51 SoC)シリーズの
仕様変更(Product Change Notice : PCN)がありましたので、
当ブログにて共有します。
お客様各位
RaytacはMDBT40 / MDBT40-PシリーズのPCNを連絡いたします。
韓国の電波安全認証KCCの承認により、
モジュールシールドケースにマークの表示が必要になりましたので、
KCCマークの印字を追加いたします。
*下記参照
kcc-mark-mdbt40
kcc-mark-mdbt40-p
変更点はこれだけです。
その他に関しては今までと変更が有りませんので、
既にご利用頂いているお客様の方で特別手続きを行ってい頂く必要は御座いません。
変更時期は2017年以降の製造分より(製造番号は7XX以降)
下記はRaytacの公式PCNとなります。
参照まで。
以上、引き続きRaytac BLEモジュールを宜しくお願いします。
